DIAMOND

Counters

Sophisticated designed counter for the astute retailer. Sophistication and descerning best describe this high end serveover counter with sharp lines and a modern design this cabinet is complimented by high temperature performance so maximise your sales with this jewel in the Pastorfrigor range.

TEMPERATURES

Class:
3H1, 3L1, 3M1, 3M2, NR, TC

Merchandising Profile:
Dairy, Milk & Cheese, Delicatessen, Fresh Meat & Fish, Frozen Food, Hot Meals, Packed Meat & Fish, Ready Meals, Sausages & Salami, Snacks & Sandwiches

Enquire Now

Key features
Dimensions

Features

Multiplexable linear modules and corners
Fan assisted cooling
Front anti-mist ventilation
Stainless steel display plates and internal body
Double LED top lighting
LED front lighting
EC fans
Panoramic sidewalls with double glazing glass
Paintable front panels with standard RAL colors

Specification

Movable and fix divider
Steps display plates
Electronic valve
Paintable or personalized front panels with optional RAL colors
Control board Master and Slave
Balance Holder
Cutting Board

Download Catalogue

Download the brochure - HQ

General

Title	Dimensions (mm)
Length without side walls	937, 1250, 1875, 2500, 3125, 3750, 45° E, 45° I, 90° E, 90° I
Length with side walls mm	1037, 1350, 1975, 2600, 3225, 3850, 3950, Not available
Thickness side walls mm	100
Width with bumper mm	1113
Height mm	870, 1180, 1606
Display surface mm	190/300/823, 400/500/846, 650, 742, 791, 850, 900
